Automatic cooking oil filling machine sauce jam honey filling capping machine

This machine is the main parts in the liquid production line, mainly used for 10~1000ml filling, feeder caps, capping. Straight line conveying, 4/6/8/16-pump linear filling, touch screen interface, frequency control. And it has the functions of lack of bottle, no bottle, no cover, etc., high degree of automation. Filling does not leak liquid, electromagnetic vibration to feed cover, equipped with dust cover. The machine is reasonable in design and easy to operate. SUS304 machine body, GMP standard and CE certificate approved.

Modelfilling machine
Bottles filling speed
15~120 bottles/min
Filling nozzle
4/6/8/12/16
Capping nozzle
1/2/4/8/10
Filling accuracy
+/- 1%
Power
Customized
Machine dimension
Customized
Machine body material
SUS304
Machine weight
Customized
Power supply
220V/380V accept customization

Product Application

Machine is suitable for automatic bottle filling, feeding caps and capping of vairous medicine, food, beverage, chemical liquid, like syrup, oral liquid, milk, juice, alcohol, wine, sauce oil, iink, solvent. etc.

1.Filling parts

Name: filling nozzle

No bottles, no filling. filling nozzle with automatic suck-back function, do dirt the bottles

2.Filliing parts

Optional 8 nozzle high speed bottle filling.

We also have 6 nozzle filling, 12 nozzle, 16 nozzle filling can customize

3.Capping parts

Name: vibration caps feeder

For caps or covers, we adopts vibrations types caps feeder. It is much more conveninet and economy.

Optionals caps elevator

Different caps need changes different caps feeder

No bottles, no filling. filling nozzle with automatic suck-back function, do dirt the bottles

4.Capping parts

Name: capping nozzle

Crimping nozzle for metal caps sealing.

Different caps may need change capping nozzle

We can do 1/2/4/6/8 different number capping nozzle

5.Capping parts

Name: capping nozzle

Different caps need change different capping nozzle.

Higher speed clamshell machine also available.

6.Control parts

Name:  touch screen

Our machine touch screen is very good and mature brand.

Can adjust the speed on the touch screen

Optional function: adjust filling volume on touch screen

CE certificate

Automatic cooking oil filling machine sauce oil bean oil filling capping machine is CE certificate approved.

Your reliable and fist choose machine supplier

Our service

Pre-Sales Service

* Inquiry and consulting support.

* Free samples testing

* View our Factory.

* Full sets spare parts

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

* 7*24 hours online free services
