Hot sale palm oil filling machine

1. This equipment is automatic washing filling capping three in one machine. It’s of many advantages, such as compact structure, perfect control system and easy to be operated. Advanced touch screen and PLC control system makes man-machine communication true.Product Description

2. Washing part is mainly composed of washing pump, bottle clamps, water distributor, up turn-plate, guide rail, protection cover, spraying device, defrosting tray, rinse water take and rinse water refluxing tank.

3. Filling Part is mainly composed of filling barrel, filling valves (normal temperature and normal pressure filling), filling pump, bottle hanging device / bottle pedestals, elevating device, liquid indicator, pressure gauge, vacuum pump, etc.

4. Capping part is mainly composed of capping heads, cap loader (separated), cap unscrambler, cap drop rail, pressure regular, cylinder and also we need an air compressor as the auxiliary external equipment.

5. Main electrical components are all imported from world famous brands to guarantee excellent performance of the whole machine.

Parameters

Filling heads	4	6	8	12	18	24
Capping heads	1	1	3	4	6	6
Capacity	300-500	600-800	1000-1200	1800-2000	2500-3000	4000-6000
Weight	800Kg	1200Kg	2000Kg	2500Kg	3200Kg	4200Kg
Motor power	2.2KW	3.7KW	5.5KW	7.5KW	11KW	15KW

Palm Oil Filling Machine
